The usage of material is in 100°C ,alkalinity ≧(20%NaOH) and other industry which request large tensile strength and large wear resistance
None
The usage of material is in 100°C ,alkalinity ≧(20%NaOH) and other industry which request large tensile strength and large wear resistance
Wood-based panels belts (also called wood-based panels processing conveyor belts)are widely used in wood-based panels , High and medium density board, veneer board, fiberboard, Oriented strand board , combination board etc ) production line , floor production line and all kinds of woodworking machinery, such as preforming press, felting machine, Finished board transportation, use of feed machine and other equipment. The Advantages of a new type prepress belt: A strong layer of high modulus made up of polyester fabrics, Under normal operating elongation can reach. 1:between the press rolls, the sawdust has the smallest expansion . 2: the minimum longitudinal compression of wood chips. 3 : the surface is very durable, and the loose amount is small . 4 : Small drafting range.
The new type of polyester fabric for wood-based panels industry has 6 advantages: 1 : High tensile strength, strong stability, Not easy to run off , wear-resisting , resistant to high temperature, Good heat dissipation, good air permeability. 2 : Safety through the needle system. 3 : three-dimensional braiding structure , No stratification . 4 : Small diameter , suitable to the conveyance of the knife mouth , Suitable for a variety of designs. 5: The antistatic black thread makes the fabric have good antistatic and anti sticking properties, effective prevention of fiber blockage,improve production efficiency. 6 : flexible selection of fabric joints include : endless joint , spiral joint , steel-clip joint and pin joint . It is easy to install, save time and improve production efficiency .
Model of Fabrics | Wire diameter (mm) | Density (wire/cm) | Strength(N/cm) | Permeability (m³/㎡h) | ||
Warp | Weft | Warp | Weft | Area of the surface | ||
16903 | 0.70 | 0.90 | 16.3 | 5.0 | ≥2200 | 7520 |
061204 | 1.20 | 1.20 | 7.0 | 4.3 | ≥2000 | 6896 |
121204 | 1.05 | 1.20 | 12.6 | 7.4 | ≥2100 | 12050 |
15905 | 0.90 | 0.90 | 15.3 | 5 | ≥4500 | 6800 |
121104 | 0.90 | 1.10 | 12.8 | 4.0 | ≥3600 | 9600 |
